115kW Heavy Fuel Engine-DB416

  • DB416发动机配置表-中英文版-20211104Download
115kW military drone engine115kW military drone engine
 115kW heavy fuel engine-DB416

 115kW military drone heavy fuel engine  Application scenarios

Application scenarios

115kW  heavy fuel engine-DB416 Main product features
Boxer 4 cylinders ,4-stroke
Suitable for heavy fuel: diesel, RP- 3/RP-5
Light-weight design, high power-to-weight ratio
No attenuation altitude 4000m/6000m, the limit altitude is 10000m/12000m
Low fuel consumption, long-endurance
TBO time > 2000h

Fuel:Diesel, Jetfuel(RP- 3/RP- 5);
Boxer 4 cylinders,Liquid-cooled,4-stroke, High pressure common rail,TCI
Maximum continuous power/Speed:150hp/4000rpm
Minimum fuel consumption:220g/kW·h
Weight(dry):102kg, 112(With reducer)
Length x widthx height:712×706×643mm (Integrated intake manifold status) 712×706×588mm(Split inlet manifold status)
Main uses:Apply to heavy load long endurance UAV, light helicopter, navigation fixed-wing aircraft, light leisure sport aircraft etc and range extenders.

Similar to thielert 165 hp heavy-fuel engine, thielert centurion 1.7 heavy-fuel engine, hfe-180hp heavy-fuel engine

115kW military drone heavy fuel engine characteristic curve
115kW heavy fuel engine characteristic curve
